Description
PRODUCT DETAILS
LS003GM101
4.0Ah battery (BL4040), Rapid charger (DC40RA) , AWS Chip (198901-5), Efficut 305 x 60T(B-67359)
- Forward Rail Design for smooth precise cutting
- Expandable sub-table for improved stability when cutting long material
- Shadow line projects cut line onto work material
- Dual zone dust extraction ports supress dust scattering of wood chips
- Compatible with AWS* for wireless connectivity with compatible dust extraction
*Requires optional wireless transmitter
Included accessories
(B-67359) Efficut 305 x 60T, (122852-0) Dust Bag, (762001-3) Triangular Rule, (126617-2) Vertical Vise, Hex Wrench and (191U61-8) Sub base assembly
Optional accessories
EFFICUT 305mm blades
AWS Chip 198901-5
Specifications
| Blade diameter | 305mm (12″) |
| Max cutting capacities | 92 x 382mm |
| – at 90° | 0° Miter: 107 x 363mm |
| – at 45° | 45° Miter, L/R: 107 x 255mm |
| – at | Miter Angle: 60° L 60° R |
| Bevel angle | 48° L 48° R |
| No load speed | 3,600 |
| Overall dimensions | 898 x 690 x 725mm |
| Net weight (skin) | 29.8kg |
| Sound Level | 100dB(A) |
| Continuous rating input | 1,500W |
| Voltage | 40V |
| XGT battery compatibility | 2Ah 2.5Ah 4Ah 5Ah |
