13% OFF
$275.00$315.00NZD incl. GST
In Stock(1 available)
1
NZ Wide Delivery
Full warranty support
Pickup in Onehunga
Additional Information
For easy decorative interior fitting applications
- Maximum precision thanks to the Bosch Pendulum Precision System
- Projection of a vertical and a horizontal line
- Detachable, 360° rotating platform with bubble vial and fine adjustment
The most important data |
|
|---|---|
| Laser diode | 630 – 650 nm, < 1mW |
| Operating temperature | -10 – 45 °C |
| Storage temperature | -20 – 70 °C |
| Laser class | 2 |
| Working range* | 15 m |
| Accuracy* | Horizontal laser line: ± 0.2 mm/m* ; Vertical laser lines: ± 0.3 mm/m* (*plus use-dependent deviation) |
| Working range of laser points, max.* | 5 m (bottom) |
| Self-levelling range | ± 3° |
| Levelling time | 4 s |
| Power supply | 4 x 1.5 V LR6 (AA) |
| Operating time (max.) | 24 h |
| Tripod thread | 5/8" |
| Weight, approx.** | 0.72 kg |
| Colour of laser line | red |
| Color of plumb points | red |
| Projection | 3 lines + 1 plumb point |
| Plumb point accuracy*** | ± 0.7 mm/m* (*plus use-dependent deviation) |
Product Details
- SKU
- 0601063M80
- Weight
- 1.5 kg
- Dimensions (L×W×H)
- 33 × 16 × 11 cm
- Category
- LASERS/LASER MEASURES
- Availability
- In Stock
